FEATURES
· Excellent reliability
· Free bending and flex resistance
· Weight Reduction
· 3D Mounting
TECHNOLOGY CAPABILITY
Layer Count | 2-26L |
Structure | HDI,Bonding structure or Mulitilayer flexible paging |
Material | PI, LCP, PTFE, FR4,TG170 |
Finished Board Thickness | 0.50mm-4.00mm |
Max Board Size | 220.00mm x 558.00mm |
Min Width of Flexible Zone | 3mm |
Min Ring Width | 4mil |
Line Width/Space | Inner:2.5mil/2.5mil;outer:3mil/3mil |
Min Hole | 0.10mm |
Aspect Ratio | 15:1 |
Dimension Tolerance | +/-0.05mm |
Surface Finish | ENIG, OSP, LF HASL, Hard gold, Immersion silver |
FEATURES
· Excellent reliability
· Free bending and flex resistance
· Weight Reduction
· 3D Mounting
TECHNOLOGY CAPABILITY
Layer Count | 2-26L |
Structure | HDI,Bonding structure or Mulitilayer flexible paging |
Material | PI, LCP, PTFE, FR4,TG170 |
Finished Board Thickness | 0.50mm-4.00mm |
Max Board Size | 220.00mm x 558.00mm |
Min Width of Flexible Zone | 3mm |
Min Ring Width | 4mil |
Line Width/Space | Inner:2.5mil/2.5mil;outer:3mil/3mil |
Min Hole | 0.10mm |
Aspect Ratio | 15:1 |
Dimension Tolerance | +/-0.05mm |
Surface Finish | ENIG, OSP, LF HASL, Hard gold, Immersion silver |
